What is a Walkabout MOTHER BIN?
A Walkabout® MOTHER BIN is an innovative grain storage solution that combines the features of a field bin with the increased storage capacity of a larger grain handling system. Unlike traditional field bins, which have a limited capacity, Walkabout® MOTHER BINS can hold significantly larger volumes of grain, specifically 110t or 165t, depending on the model chosen.
Walkabout® MOTHER BIN Specs
The Walkabout® MOTHER BIN bridges the gap between a grain cart and a truck by storing up to 110t or 165t bushels of grain. Its purpose is to enable combines and grain carts to continue harvesting without having to wait for trucks.
WMB 110T Eastern Grey
- 110t capacity
- AGRI-COVER® Solar Operable Electric Roll Tarp
- Split front and rear flow gates for blending grain
- 22″ unload auger
- Up to 24t per minute unload rate
- Camera system: OverView® 1080P HD Digital 7″ Wireless Waterproof Monitor and 120° Camera
- Optional downforce hitch
- Adjustable auger spout
- Self-steering front and force steering rear axles
- Rear access door
- Movable while partially loaded
- Full length clean out doors
- Minimum 230hp
- Outback Wrap Hydraulic Hose Markers on each bin
- 18m long x 4.18m wide x 4.03m high
WMB 165T Big Red
- 165t capacity
- AGRI-COVER® Solar Operable Electric Roll Tarp
- Split front and rear flow gates for blending grain
- 22″ unload auger
- Up to 24t per minute unload rate
- Camera system: OverView® 1080P HD Digital 7″ Wireless Waterproof Monitor and 120° Camera
- Remote unload
- Adjustable auger spout
- Self-steering front and force steering rear axles
- Rear access door
- Movable while partially loaded
- Full length clean out doors
- Minimum 300hp required
- Downforce hitch (standard)
- Outback Wrap Hydraulic Hose Markers on each bin
- 21.65m long x 4.5m wide x 4.14m high
Request a Quote
2025 AE50 Award Winner
According to Farm Equipment “A WMB is the difference between harvesting crops at near 100% efficiency vs. the accepted efficiency of just 60-70%.
Frequently Asked Questions
What is your logistics pricing?
We provide services that can assist in logistics either port to port or as extensive as door to door.
Can the Mother Bin be containerized?
Yes, either model can fit within two forty-foot shipping containers.
Does your company assemble the Mother Bin?
Yes, we provided an assembly team or an assembly foreman. We work with customers on assembly location, depending on customer capabilities.
Can a Mother Bin be used as a seed tender?
With its 110t or 165t capacity, seed trucks are able to tender out of the mother bin while being positioned in a central location during planting time.
